INSTRUMENTS AND CONTROLS 91 1. Handle in Right Turn Position and Cancel Position of Hazard Warning
4. Push for Courtesy Flashing of High Beams
2. Handle in Left Turn Position and Cancel Position of Hazard Warning
5. Push for Courtesy Flashing of Marker Lights (Daylight or Dark)
3. Pull for Warning Hazard Position
6. Lift Handle for Headlight Dimmer
Stalk Switch (If Equipped, Co-Pilot® Only) The stalk switch (Co-Pilot® only) is located on the right side of the steering column and contains three depressible buttons: ESC, Enter (↵ ) and Up & Down. The stalk switch is used to access, navigate, view and change information available in the driver information display (Co-Pilot® display). The following illustration shows the stalk switch.
C0029226
1. ESC (Escape)
3. Up & Down
2. ↵ (Enter) Navigation of Co-Pilot® Menu ESC BUTTON The ESC (Escape) button on the stalk switch takes the Co-Pilot® back to the previous screen or level in the menu. Note: The ESC button does not function at Start Up or when the vehicle is moving. The ESC button is used only when the vehicle is stationary. ↵ ) BUTTON ENTER (↵ The Enter (↵ ) button on the stalk switch selects the highlighted menu items during menu selection. During Start Up and when moving the vehicle, the Enter(↵ ) button is also used to confirm or acknowledge a pop-up screen. https://www.truck-manuals.net/
