METHOD FOR DISCONNECTING AND CONNECTING DEUTSCH CONNECTOR
METHOD FOR DISCONNECTING AND CONNECTING DEUTSCH CONNECTOR Method for disconnecting Deutsch connector While pressing locks (a) and (b) from each side respectively, pull out female connector (2).
Method for connecting Deutsch connector 1.
Push in female connector (2) horizontally, and insert it straight until it clicks. (Arrow: x)
2.
In order to check whether locks (a) and (b) are completely inserted, insert female connector (2) by rocking it vertically (in the arrow z direction). (Arrow: x, y, z) REMARK Lock (a) in the figure is pulled down (not set completely), and lock (b) is set completely.
