DISCONNECT AND CONNECT PUSH-PULL TYPE COUPLER
2.
00 INDEX AND FOREWORD
After inserting the hose in the mating adapter perfectly, pull it back to check the connecting condition. REMARK When the hose fitting is pulled back, the rubber cap moves approximately 3.5 mm toward the hose, but it is not a problem.
METHOD FOR DISCONNECTING AND CONNECTING TYPE 2 PUSH-PULL TYPE COUPLER Disconnection 1.
Hold the tightening adapter part and push body (2) straight until sliding prevention ring (1) contacts contact surface (a) of the hexagonal part at the male end.
2.
While keeping the condition of step 1, turn lever (3) to the right (clockwise).
3.
While keeping the conditions of steps 1 and 2, pull out whole body (2) to disconnect it. REMARK Provide an container to receive a quantity of hydraulic oil which may flow out.
00-42
95LE-7 SERIES
