REMOVE AND INSTALL ENGINE FRONT OIL SEAL
50 DISASSEMBLY AND ASSEMBLY
Crankshaft pulley assembly 4. Remove the bolt (3), and remove the plate (4) and crank pulley assembly (5).
Front oil seal 5. Remove the front oil seal (6).
METHOD FOR INSTALLING ENGINE FRONT OIL SEAL 1.
Install the front oil seal (6) by using the push tool (Q) and hammer. NOTICE Check that the end surface, corner and the lip sliding surface of the crankshaft are free from a flaw, burr, fin, rust, and etc. before installing the front oil seal.
2.
After press fitting the front oil seal, fill the clearance between the seal lips with approximately 2 cc of grease.
2 Front oil seal (6): Grease (G2-LI)
Crankshaft pulley assembly 3. Install the crankshaft pulley assembly (5) and plate (4) with the bolt (3). 3 Bolt (3): 343 to 402 Nm {35 to 41 kgfm}
50-90
95LE-7 SERIES
