REMOVE AND INSTALL SUPPLY PUMP ASSEMBLY
50 DISASSEMBLY AND ASSEMBLY
18. Remove the nut (19), washer (23), and gear (21) from the shaft (20).
METHOD FOR INSTALLING SUPPLY PUMP ASSEMBLY Supply pump assembly 1. Install the gear (21), washer (23), and nut (19) to the shaft (20). 2. Tighten the nut (19). 3 Nut (19): 58.8 to 68.6 Nm {6.0 to 7.0 kgfm}
3.
Align the supply pump assembly and gear (21) with the mounting positions according to the following procedure. 1) Match the top positions of the engine pistons #1 and #4. 2) Install it with the stamp mark “C” (c) of the gear facing the idler pulley.
50-86
95LE-7 SERIES
