DISASSEMBLE AND ASSEMBLE ENGINE GENERALLY
50 DISASSEMBLY AND ASSEMBLY
178. Tighten the bolts (28) (4 pieces) of the exhaust pipe (1)
lightly. 179. Tighten the bolt (15) of the lower clamp (16) to the speci-
fied torque.
3 Bolt (15): 59 to 74 Nm {6.0 to 7.5 kgfm}
180. Loosen the bolts (11b) and (11a), insert the plate (D) into
the clearance on the bottom side of the clamp (12), and tighten the bolt (11a) lightly. 181. Tighten the bolt (11b) and nut (11c) to the specified torque.
3 Bolt (11b): 14 Nm {1.5 kgfm}
182. Remove the plate (D), and tighten the bolt (11a) to the
specified torque.
3 Bolt (11a): 14 Nm {1.5 kgfm}
183. Retighten the bolts (11b) and (11a).
3 Bolts (11b),(11a): 27 to 34 Nm {2.8 to 3.5 kgfm}
184. Tighten the bracket (14) lightly with the bolts (3) and (13). 185. Tighten the bolts (28), (3) and (13) to the specified torque.
3 Bolt (28): 59 to 74 Nm {6.0 to 7.5 kgfm} 3 Bolt (3): 27 to 34 Nm {2.8 to 3.5 kgfm}
50-80
95LE-7 SERIES
