DISASSEMBLE AND ASSEMBLE ENGINE GENERALLY
50 DISASSEMBLY AND ASSEMBLY
161. Install the bracket (3) with the bolts (3a) (2 pieces). 162. Install the hose (1) with the bolts (1a) and (1b). 163. Install the hose (2) with the bolts (2a), (2b), (2c), and (2d).
Exhaust throttle valve 164. Install the bracket (25) with the bolts (24) (2 pieces). 165. Install the bracket (27) with the bolts (26) (3 pieces).
166. Install the bracket (23) with the bolt (22).
3 Bolt (22): 59 to 74 Nm {6.0 to 7.5 kgfm}
167. Install the exhaust throttle valve (21).
NOTICE A pin is provided at the installing part (d) on the turbocharger side. Install the exhaust throttle valve (21) horizontally to the pin.
50-78
95LE-7 SERIES
