DISASSEMBLE AND ASSEMBLE ENGINE GENERALLY
50 DISASSEMBLY AND ASSEMBLY
Supply pump assembly 69. Install the gear (21), washer (23), and nut (19) to the shaft (20). 70. Tighten the nut (19). 3 Nut (19): 58.8 to 68.6 Nm {6.0 to 7.0 kgfm}
71. Align the supply pump assembly and gear (21) with the mounting positions according to the following procedure. 1) Match the top positions of the engine pistons #1 and #4. 2) Install it with the stamp mark “C” (c) of the gear facing the idler pulley.
3)
When installing the supply pump assembly to the front cover, align straightly the tapped hole (a) of the gear with the tapped hole (b) of the front cover viewed from the engine front.
72. Install the supply pump assembly (18) with the bolt (17).
50-60
95LE-7 SERIES
