DISASSEMBLE AND ASSEMBLE ENGINE GENERALLY
50 DISASSEMBLY AND ASSEMBLY
Disassembling the cylinder head assembly 92. Disassemble the cylinder head assembly. 1)
By using the spring pusher (E), compress the valve spring (3), and remove the cotter (4).
2)
Loosen the spring pusher (E) slowly, and remove the valve spring seat (5) and valve spring (3).
REMARK Remove these parts for all cylinders according to the same procedure.
93. Turn the cylinder head assembly upward, and remove the intake and exhaust valves (1) (16 pieces). REMARK Put marks on the intake and exhaust valve (1) so that you can find matching cylinder head.
Valve guide and valve seal 94. Remove the valve seals (1) (16 pieces).
50-36
95LE-7 SERIES
