DISASSEMBLE AND ASSEMBLE ENGINE GENERALLY
50 DISASSEMBLY AND ASSEMBLY
Rocker arm assembly 83. Loosen the lock nuts (1) (8 pieces) and fully loosen the adjustment screws (2) (8 pieces). 84. Remove the bolts (3) (10 pieces), and remove the rocker arm assembly (4).
Push rod and crosshead 85. Remove the push rods (1) (8 pieces). 86. Remove the crossheads (2) (8 pieces). REMARK Record the mounting positions and hole shapes of the portions (a) and (b). (To assemble them correctly in the same direction again)
Injector assembly 87. Remove the bolts (1) (4 pieces), and remove the injector holders (2) (4 pieces). REMARK Do not reuse the bolts. Replace them with new ones.
50-34
95LE-7 SERIES
