DISASSEMBLE AND ASSEMBLE ENGINE GENERALLY
50 DISASSEMBLY AND ASSEMBLY
Fan pulley, idler pulley, and tensioner assembly 50. Remove the bolt (1a), and remove the clamp. 51. Remove the bolts (1) (6 pieces), and remove the fan pulley assembly (2). 52. Remove the bolts (3) (3 pieces), and remove the idler pulley assembly (4). 53. Remove the bolt (5), and remove the tensioner assembly (6). 54. Remove the bolts (7) (3 pieces), and remove the plate (8). Bracket and wiring harness assembly 55. Remove the bracket (1). 56. Disconnect the wiring harness assembly (2). REMARK When disconnecting the wiring harness assembly (2), check the positions of each clamp and connector.
Thermostat assembly 57. Loosen the clamp (1), and disconnect the hose (2). 58. Remove the bolts (3) (4 pieces), and remove the coolant outlet connector (4).
59. Remove the thermostat (5). 60. Remove the coolant temperature sensor (6).
50-30
95LE-7 SERIES
