DISASSEMBLE AND ASSEMBLE ENGINE GENERALLY
50 DISASSEMBLY AND ASSEMBLY
35. Remove the bolts (3a) and (3b), and remove the bracket (3c).
36. Remove the bolts (4) and (5), and remove the tube (6). 37. Remove the bolts (7) (2 pieces) and bolt (8), and remove the tube (9). 38. Remove the hose clamp (10) and bolt (11), and remove the tube (12).
39. Remove the joint bolts (13) and (14), and remove the tube (15).
40. Remove the bolts (16) and (17), and remove EGR cooler assembly (18).
Exhaust manifold 41. Remove the bolts (1a) (4 pieces), and remove the brackets (1b) and (1c).
50-28
95LE-7 SERIES
