50 DISASSEMBLY AND ASSEMBLY
DISASSEMBLE AND ASSEMBLE ENGINE GENERALLY
Turbocharger assembly 26. Remove the bolts (1a) and (2b), and remove the hose (1). 27. Remove the bolts (2a), (2b), (2c), and (2d), and remove the hose (2). 28. Remove the bolts (3a) (2 pieces), and remove the bracket (3).
29. Disconnect the tube clamp (4). 30. Remove the bolts (5) and (6), and remove the tube (7).
31. Remove the bolts (9) (2 pieces) of the lubricating oil drain tube on the turbocharger side.
32. Remove the nuts (8) (4 pieces). 33. Remove the turbocharger assembly (10).
EGR cooler assembly 34. Remove the bolts (1) (3 pieces) and bolts (2) (2 pieces), and remove the tube (3).
95LE-7 SERIES
50-27
