DISASSEMBLE AND ASSEMBLE ENGINE GENERALLY
50 DISASSEMBLY AND ASSEMBLY
Preparation 1. Set the engine assembly (1) on the block (A). REMARK The weight of the engine assembly (1) may vary depending on the mounted machine model. 4 Engine assembly (1) : 430 kg
2.
Drain the engine oil. REMARK The oil level may vary depending on the mounted machine model. 6 Engine oil: 11.5 ℓ
Engine controller assembly, fuel filter assembly, and engine oil filter assembly 3. Remove the engine controller assembly (1). NOTICE Put the masking on each connector part of the engine controller assembly. 4.
Remove the fuel filter assembly (2) together with the hose as a unit.
5.
Remove the engine oil filter assembly (3) together with the hose as a unit.
Exhaust throttle valve 6. Remove the bolts (2) (4 pieces) and bolt (3) (1 piece) of the exhaust pipe (1).
7.
Remove the bolts (3 pieces), and remove the cover (5).
50-22
95LE-7 SERIES
