C Transport 1
Safety regulations for transport
$
There is a risk of accident if the machine is prepared incorrectly and transportation is conducted incorrectly Prepare the machine ensuring that all components are secured and cannot come loose. Dismantle all protruding and removable components and/or fit them so that they do not represent a hazard! The weather protecting sun roof should be deployed and appropriately fastened during transport. Lower all of the machine down to the upper section of the separated service supports. When in this position, the bit tips of the milling drum are approx. 1 cm above the ground. If a wooden support is fitted, the milling drum can rest gently on this. The upper conveyor should also be moved into its floating position if necessary. The machine should be fastened onto the attachment points provided for this purpose and fixed to the transporter in accordance with the relevant regulations. Ensure that the transport vehicle is authorised for transport of this type and that the maximum transport load is not exceeded. Store all components which are not permanently connected to the machine in the boxes and storage areas provided. Close all panels and check that they are securely fastened. Use the cover to secure the main control panel, close the side operating units.
When loading via ramps, there is a risk that the machine will slip, tilt or overturn.
Drive carefully! Keep people away from the danger area! The following applies in addition to the above during transport on public roads: The machine driver must have a valid driving licence for this type of vehicle.
C_PL2000S_2000LS_GB.fm. 1-16 04-01.07
The operating panel must be on the side facing oncoming traffic and be secured in place. The headlights must be set in accordance with the relevant regulations. When driving on public roads, if necessary, another person must guide the machine driver – especially at crossroads and side-road junctions. Note the load bearing capacity of vaults and bridges as well as the permissible transport height and width.
C1
