9
Malfunctions
9.1
Error code retrieval for engine If an error detected on the engine has been indicated by one of the warning lamps (1) or (2), a code to which a defined error is assigned can be displayed using the retrieval switch for error / malfunction retrieval (3). The flash code is issued by the second warning lamp. If an error is displayed in warning lamp (1), it is issued by warning lamp (2) and vice versa.
3
D_PL2000S_2000LS_GB.fm. 131-146 04-01.07
1
2
PL2000LS_Contr_conv_top2.wmf/checklights2.wmf
Output of numerical code - Press switch (3) until the three-digit code has been issued by the warning lamp. While the error retrieval switch is pressed, the warning lamp which originally indicated the error goes out.
D 131
