External starting (starting aid)
3
PL2000LS_Contr_conv_top2.wmf/
If the batteries are flat and the starter is not turning, the engine can be started using an external source of power. The following are suitable as sources of power: - another vehicle with a 24 V system; - additional 24 V battery; - starting aid, 20V/100A.
$
Normal charge devices and rapid charge devices are not suitable as starting aids. To externally start the engine: - Use appropriate cables to connect source of power up to batteries.
D_PL2000S_2000LS_GB.fm. 115-146 04-01.07
$
Check correct polarity! Always connect the negative cable last and remove it first! - Insert ignition key (3) into position „0“ in the ignition lock. - Switch on ignition (Item 1). - Rotate ignition key to (position 2) to start the diesel engine. - Once the diesel engine has started up, release the ignition key. - The ignition key will automatically jump back to position 1. Should the engine not start despite the starting aid: find out why, consult the engine's operating instructions if necessary. Once the engine is running:
- disconnect external source of power. When using starter aid spray, note the engine's Operating instructions.
D 115
