6.5
Actual value calibration
Digi-Slope sensor (transverse slope sensor) During this process, the actual value display of both digital controllers is compared with the actual slope angle of the machine / milling drum
Initial situation for actual value calibration - Sensors and controllers are fitted, all connection cables are connected. - The machines is standing on as smooth and level the surface as possible, without any slope, and is smoothly lowered via the strut towers so that the milling drum is just above the ground. - The side boards are lowered. - The milling drum is activated, the diesel engine runs at idle speed. - The scraper board is raised slightly and provides a clear line of sight to the rotating milling drum and the ground.
Other tasks
D_PL2000S_2000LS_GB.fm. 99-146 04-01.07
- Use the appropriate function switch on the side operating unit to lower the machine slightly more at the rear than the front without the rotating milling drum touching the ground. - Use the buttons (7) to slowly and smoothly lower the left and right of the machine until the entire width of the rotating milling drum and the bit tips scratch against the base. - Both side boards lie evenly on the ground, the machine is horizontal (front and rear at the same height).
7
Pult3a_LS.tif /Moba1.cdr
D 99
