6.4
Calibration to zero
Initial situation for calibration to zero - Sensors and controllers are fitted, all connection cables are connected. - The machine is standing on as smooth and level the surface as possible, without any slopes, and is smoothly lowered via the strut towers so that the milling drum is just above the ground. - The side boards are lowered - The milling drum is activated, the diesel engine runs at idle speed. - The scraper board is raised slightly and provides a clear line of sight to the rotating milling drum and the ground.
Other tasks - Use the appropriate function switch on the side control panel to lower the machine slightly more at the rear than the front without the rotating milling drum touching the ground. - Use the buttons (7) to slowly and smoothly lower the left and right of the machine until the entire width of the rotating milling drum and the bit tips scratch against the base. - Both side boards lie evenly on the ground, the machine is horizontal (front and rear at the same height).
D_PL2000S_2000LS_GB.fm. 93-146 04-01.07
7
Pult3a_LS.tif /Moba1.cdr
D 93
