5
Levelling equipment
5.1
MOBA-matic type The MOBA-matic is a control and feedback control system for construction machinery and has been especially designed for use in cold planers. The Moba-matic is available with a large number of sensor combinations. - (1):cable sensor (distance sensor) - (2):Digi-Sonic sensor (distance sensor) - (3):Sonic-Ski (distance sensor) - (4):Digi-Rotary sensor (distance sensor) - (5):laser receiver (distance sensor) - (6):Digi-Slope sensor (slope sensor)
As standard, the machine is fitted with two digital controllers and two cable sensors or ultrasonic sensors (Digi-Sonic) which act on the side boards. The use of a transverse slope sensor (Digi-Slope) and the other sensor types is optional. The digital controller automatically detects the sensor connected during setting and briefly indicates this through the sensor detection.
1
2
3
4
5
6
D_PL2000S_2000LS_GB.fm. 76-146 04-01.07
Robe.jpg/Sonic2.jpg/Sonic.jpg/Rotary.jpg/Laser.jpg/slope.jpg
D 76
