Water system
2 6
7
5 8
1 9
10
11
3
4
Wasserfilter4_LS.wmf
The water system on the right-hand side of the machine comprises the following elements: - Roller pump (1): to produce pressure --> water spraying system, cleaner 10 bar ( ). - High pressure pump ( ) (2): to produce pressure --> high pressure cleaner 130 bar. - 75 micron upstream filter (3): The only filter used when the high pressure pump is not fitted. - Additional 10 micron filter ( ) (4): Additional filter fitted when the high pressure pump is fitted. - Pressure gauge for water pressure (5): Indicates the set water pressure.
&
&
D_PL2000S_2000LS_GB.fm. 59-146 04-01.07
&
$
Set water pressure to no more than 10 bar! - Setting handle for water pressure (6): Adjustment range 0 - 10 bar. - Vent lever (7): no function - Tank water supply shut-off valve (8): to shut off the water supply from the tank, e.g. for maintenance work. - Front shut-off valve- spray nozzles - milling drum box (9): - Rear shut-off valve- spray nozzles - milling drum box (10): - Shut-off valve- spray nozzle for lower conveyor (11):
&
When the cleaner ( ) is fitted, stop cock (9) for the front and rear spray nozzles on the milling drum box and stop cock (10) for the cleaner are also fitted! Shut off any connections not used and fit with blind plugs! D 59
