4
Controls
4.1
Controls at operator’s control station
Driver’s seat on left / right A driver’s seat can be found on both the left and right. The seat should be set to the driver’s requirements before work is started. - To set the correct seat hardness, fold the crank on the handwheel (1) forwards and rotate until the approximate weight of the driver appears on the display (2). - To set the correct distance from the operating panel, pull lever (3) upwards and slide the seat forwards or backwards as required. - Pull up the grip recess (4) on the back of the seat and set the height of the backrest. - Should the driver’s seat have to be moved beyond the outer edge of the machine, the locking lever (5) must be applied and the complete seat bracket moved in the corresponding direction. Then move the lever back to lock. The armrests ( ) can also be swivelled upwards.
3 5 1 2
4
&
Risk of accident! If possible, always select the operator's control station on the nearside, i.e. furthest away from oncoming traffic.
D 50
Always ensure that the operating panel and driver's seat are correctly locked into place.
