Hydraulic System Design A 80V / 23,5 kW threephase motor is used to drive the pump. The thermal gauge for temperature control is sealed in a field coil, the speed sensor is located in the sensor bearing. Motor overtemperature is displayed via an indicated in the multi-function display.
fig. 80
Item
80
Description
Item
Description
1
Pump motor
5
Measurement port
2
Cross coupling
6
Pressure filter
3
Hydraulic pump
4
Hydraulic oil reservoir
7
Sensor bearing and temperature gauge connector
