Control valve standard setting

Control valve standard setting

Solo Pilot

fi g. 166

Item Description Function

electrical

1 Lowering brake 2 Pressure relief valve 3 Reservoir return connection 4 Pressure port 5 Lift port 6 2R3/XB 29 Lift potentiometer 7 2S73/XB 75 Fwd/rev tilt switch 8 2S57/XB 76 ZH1 valve switch 9 2S76/XB 77 ZH2 valve switch

Option ZH1, ZH2

When attaching additional equipment adjust the oil volume required via the pump speed. The pump speed must always be appropriate to the pressure. Increasing the pump speed in excess of 35-40 l/min results in just a minimal increase in speed but a considerable rise in pressure. (Oil heating, energy loss)

Intermediate settings can be made by adjusting the lever accordingly.

Increasing the pump r.p.m. does not increase the speed (shorter tilt times), it simply increases pressure loss from the current controller. No other settings are possible. The tilt speed is restricted by a current control valve to a maximum tilt time of approx. 3,5-4 seconds or 24 l/min. When adjusting the tilt speed by increasing the pump speed always check the pressure as well.

Multi Pilot

Standard version

1 2 3 4 5 6 7

13 12 11 10 9 8

fi g. 167

When adjusting the tilt speed by increasing the pump speed always check the pressure as well. If the pressure rise is too great (over 70-80 bar idle speed) the limit stop on the spool valve must be adjusted (screws 4 and 10).

Item Description hydraulic electrical Function

m1/2Y1 Lifting1 XB29 m2/2Y5 Lowering, volume control 2 Emergency drain 3 PRV Pressure relief valve 4 Volume adjustment, forward tilt 5 m6/2Y47 XB47 Rev. tilt 6 m3/2Y65 XB49 Sideshift left 7 m7/2Y66 XB51 ZH2 left 8 m8/2Y67 XB50 ZH2 right 9 m4/2Y64 XB48 Sideshift right 10 Volume adjustment, rev. tilt 11 m5//2Y46 XB46 Fwd. tilt 12 Measurement connection 13 Lowering speed

If synchronous “Lift/Reach” is required for the sideshift, fi t a diaphragm in port “A”. The pump speed and pressure must be tuned, with the maximum volume being approx. 25 l/min.
