When adjusting the tilt speed by increasing the pump speed always check the pressure as well.
Control valve standard setting Solo Pilot
Item
Description
Function
electrical
1
Lowering brake
2
Pressure relief valve
3
Reservoir return connection
4
Pressure port
5
Lift port
6
2R3/XB 29
Lift potentiometer
7
2S73/XB 75
Fwd/rev tilt switch
8
2S57/XB 76
ZH1 valve switch
9
2S76/XB 77
ZH2 valve switch
Option ZH1, ZH2 When attaching additional equipment adjust the oil volume required via the pump speed. The pump speed must always be appropriate to the pressure. Increasing the pump speed in excess of 35-40 l/min results in just a minimal increase in speed but a considerable rise in pressure. (Oil heating, energy loss) fig. 166
Intermediate settings can be made by adjusting the lever accordingly. Increasing the pump r.p.m. does not increase the speed (shorter tilt times), it simply increases pressure loss from the current controller. No other settings are possible. The tilt speed is restricted by a current control valve to a maximum tilt time of approx. 3,5-4 seconds or 24 l/min.
166
