Steering angle sensor replacement / adjustment Preparation • Park the truck securely • Fully lower the load lifting device • Set the main switch and key switch “OFF” Disassembly • Disconnect sensor cable connection. • Undo steering angle sensor mounting bolts (1) Assembly • Insert the steering angle sensor (2), set to 46 mm distance and tighten the mounting bolts (1). • Check the distance between the magnet and the sensor, approx. 3-4 mm, adjust if necessary. • Re-connect the sensor cable connection (interface)
