Error List (not password protected) Location
Error type
01 ... 04
Spare
05 ... 19
Digital outputs
Ppriority
Description, Action
05=DO1, 06=DO2, 07=DO3, 08=DO4, 09=DO5, 10=DO6, 11=DO7, 12=DO8, 13=DO9, 14=DO10, 15=DO11, 16=DO12, 17=DO13, 18=DO14, 19=DO15
02
Wire breakage
1
A wire breakage has been detected on the respective output. Check wiring! Troubleshooting aids: remove the connector and measure the resistance on respective terminals of the plug connector to check the individual valve coils. On-off valves typically have a 15 to 30 ohm coil resistance. If several outputs are reporting broken wires, an interrupted common return line is probably the cause. If the resistance measurement cannot detect a problem, the cross-section of the common return line may be too small.
03
Short circuit
3
A short circuit has been detected on the respective output. Check wiring. Troubleshooting aids: Remove the controller and measure the resistance and voltage on the respective terminals to determine the type of short circuit. Short circuits to earth or to +24 volts are possible. The voltage must not exceed 3V on the output terminals.
05
Parameter prog
3
Computer internal configuration error
12
> max. value
3
Computer internal configuration error
