Special Function Menu The special function menu is activated by pressing the ENTER and ESC keys simultaneously for at least 3 seconds.
STOP
Attention: The parameters are factory-set and must not be changed.
4. Calibration In this menu item sensors can be read and adjusted. A password must be entered. Display text: “alignment” 5. Version display In this menu item the versions of the various software modules can be displayed. Display text: “version display” 6. Menu items are selected with the ENTER key. The ESC key forces the display to return to the basic setting.
Press simultaneously for 3 seconds fig. 100
The change is complete when the “i/o data display” changes. The special function menu offers the following items: 1. Input and output signals In this menu item you the status of the input and output signals can be seen. Display text: “i/o data display” 2. Error log In this menu item the error log can be read and deleted. Display text: “error memory” 3. Parameters In this menu item parameters can be read and changed. A password must be entered to change parameters. Display text: “parameters”.
100
