BI620114
Service Manual
PACKING/SUPPORTING THE MACHINE To support the machine or to raise the body of the machine perform the following: 1. 2. 3. 4. 5.
6.
7.
Lower the lift arms and remove any attachments. Park the machine on flat, level ground. Ensure the machine is in a straight line. Ensure that the engine has had sufficient time to cool and is isolated and tagged as described in this section - Machine Isolation. Fit the articulation lock. Follow the procedure for isolating the machine hydraulic system. Check that both the steering and brake pressure gauges in the operator’s compartment are reading zero pressure. Raise the wheel to be changed with a suitable rated device (e.g. chain block, hydraulic jack, air bag, etc). See diagram for the suitable lifting and support points for the machine’s chassis. Place the machine on suitable stands or blocks that will allow the removal of the wheels. Do not rely on the lifting equipment alone to support the machine when working beneath it. The machine must be supported by stands or similar.
These are recommended jacking, chocking, lifting and tow positions for anything outside this scope contact Bucyrus.
The tyres on the machine have a solid rubber option, extreme care should be taken when removing these wheels because of their mass. 24
FBL-10 LHD/Utility Serial No. 1600
Rev. 2
