Sensors & Locations Engine Coolant Level Sensor The engine coolant level sensor is located in the engine make up tank adjacent to the engine. This sensor monitors the engine coolant level and will shut the machine down by stopping power to the fuel solenoid valve. The fuel solenoid valve will open exhausting air pressure from the system thus the fuel shutdown cylinder will close the fuel rack, this closes of fuel to the engine and shuts the engine down. There is no need for routine calibration of the coolant level sensor as long as routine testing is carried out.
Engine Coolant Level Sensor
Low Hydraulic Oil Sensor The low hydraulic oil level sensor is located on the inspection cover of the hydraulic tank, when the oil level drops below the prescribe level the machine will display a message.
Low Hydraulic Oil Sensor
