Electrical system _________________________________________________ Starter enclosure The starter enclosure, located on the left side of the machine, houses the primary electrical control components. WARNING! Before removing the cover from the starter enclosure and attempting any maintenance or troubleshooting on the machine, the main power must be disconnected and locked and tagged out at the main power center. There are operational controls located on the front of the starter enclosure (Fig. 25). For control descriptions, see the Controls and Indicators section in this chapter. Fig. 25: Starter enclosure 1
6 5
4
3
10
8 7
1. 2. 3. 4. 5. 6. 7.
2
9
11
13
12
“MAN/OFF/AUTO” selector switch “TRAM/OFF/CONV” selector switch “FWD/OFF/REV” selector switch PLC display “CB RESET” pushbutton “CONVEYOR START” pushbutton “CONV. HOUR METER” digital display
8. 9. 10. 11. 12. 13.
“START BREAKER” pushbutton “STOP” pushbutton “ACKNOWLEDGE ALARMS” pushbutton “BRKR. HOUR METER” digital display “EMERGENCY STOP” pushbutton Main circuit breaker reset lever
________________________________________________________________ Cat® FB110 Feeder Breaker 5.32
