Conveyor drive

The conveyor motor drives the headshaft and conveyor system (Fig. 34). Torque from the motor is transmitted to the head shaft assembly.

Fig. 34: Conveyor drive main components

1

2

1. Connecting link 2. Hydraulic motor 3. Torque arm 4. Coupling 3 4
