____________________________________________________ Maintenance Monthly crawler anchor pins
Lubricate grease fittings on both left and right side crawler anchor pins with Spec. 100-3 (Fig. 51). Pump grease into the fittings until new grease can be observed coming out of the pins. Fig. 51: Crawler anchor pin lubrication
Crawler anchor pin (s) (grease fitting located inside crawler frame) breaker electric motor
Lubricate the breaker power unit electric motor with Spec. 100-14 or Spec. 100.16 high temperature grease through the two (2) grease fittings located on the lubrication manifold (Fig. 52) on the right side of the machine. Pump only one or two pumps of grease into each fitting. NOTICE! Incorrect grease or over greasing may cause serious damage to the electric motor.
breaker reducer
Lubricate the breaker reducer with Spec. 100-3 through the two (2) grease fittings located on the remote grease block (Fig. 52). Pump only one or two pumps of grease into each fitting using a hand grease gun. IMPORTANT! Rapid greasing with a power grease gun can force grease inward past the seals, causing seal leaks.
______________________________________________________________ A6474X435 REV 2 5.69
