93
ASSEMBLY OF THE FOUR-WHEEL DRIVE VALVE (IF EQUIPPED) STEP 385
STEP 388
BP95F361 Install a new O-ring on the nut. Use clean transmission oil to lubricate the O-ring. New O-rings for the nut and solenoid are provided in the overhaul kit.
BP95F358 Install the solenoid valve in the solenoid valve body. Tighten the solenoid valve to a torque of 195 pound-inches (22 Nm).
STEP 389 STEP 386
BP95F357 BP95F359 Install the three new O-rings on the solenoid valve. Use clean transmission oil to lubricate the O-rings.
Install a new O-ring on the solenoid valve. Use clean transmission oil to lubricate the O-ring.
STEP 390 STEP 387
BP95F355 BP95F362
Install the solenoid coil on the solenoid valve.
Install the check valve in the valve body as shown.
Bur 7-54022
Issued 10-97
Printed in U.S.A.
