ASSEMBLY OF THE SHIFTER HOUSING STEP 370
STEP 373
BP95F346 Apply lithium grease to the ball of the new shift lever. Install the shift lever in the shifter housing.
BP95F349 Install the new bushing from the update kit.
STEP 374 STEP 371 2 4 3
1
BP95F344 BP95F352
The correct alignment of the shift lever and the shifter housing is shown above. The slot (1) in the shift lever must be toward the flat side (2) of the flange on the shifter housing. The slots (3) on each side of the shift lever must be aligned with the holes (4) in each side of the shifter housing.
Put a new snap ring from the update kit on the shift lever. Use a 5/8 inch deep socket to push the snap ring into the snap ring groove.
STEP 375
STEP 372
BP95F343
BP95F347
Install the new pins from the update kit through the holes in the shifter housing so that the pins engage the slots in the shift lever.
Install the new spring from the update kit.
