DISASSEMBLY OF THE FOUR-WHEEL DRIVE SHAFT STEP 345
STEP 347
BP95F279 There is a pipe plug at the bottom of the hole in the end of the shaft (see arrow). DO NOT remove the pipe plug unless the pipe plug is damaged.
BP95F274 Remove and discard the snap ring from the shaft.A new snap ring is included in the overhaul kit.
STEP 348 STEP 346
BP95F276 BP95F273 Use an acceptable tool to press the spring retainer down until you have access to the snap ring (see arrow). Remove the snap ring from the groove. Release the tension and remove the tool.
Remove and discard the spring retainer. A new spring retainer is included in the overhaul kit.
STEP 349
NOTE: The tool used in the photo above is a piece of round tubing with a rectangular access hole cut out.
BP95F275 Remove and discard the springs. New springs are included in the overhaul kit.
