INSPECTION OF THE PRIMARY SHAFT STEP 291
STEP 293
Check the teeth on the gears for wear and damage. If a tooth is badly damaged, be sure to inspect the gear or spline that is in mesh with the damaged gear.
Check the ball bearing for flat areas, pitting, and other damage. Replace as necessary.
STEP 292 Check the splines on the primary shaft for wear and damage.
NOTE: Clean bearings and gears with clean transmission oil, compressed air, and lint free shop towels. If inspection reveals problems with any of the primary shaft assembly parts, replace as necessary. Be sure to check for evidence of similar problems with the mating par ts.
1 2 4
3
5
6
7
BT95G177
1. Snap Ring 2. Bearing and Snap Ring
Bur 7-54022
3. Thrust Washer 4. Small Gear
5. Large Gear 6. Primary Shaft
7. Bearing
