DISASSEMBLY OF THE PRIMARY SHAFT STEP 284
STEP 286
BP95F194 Put the primary shaft on the bench so that the end with the bearing attached is up. Remove and discard the snap ring. A replacement snap ring is provided in the overhaul kit.
BP95F196 Remove the bearing and set aside to be examined later.
STEP 287
STEP 285
BP95F197 BP95F195 Install a bearing separator under the gear as shown. DO NOT install the bearing separator between the gear and the bearing. Install an acceptable puller on the bearing separator. Use a shaft protector between the puller and the end of the primary shaft. Use molydisulfide grease to lubricate the shaft protector and the end of the puller. Pull the bearing from the primary shaft.
Remove and discard the thrust washer. A replacement thrust washer is provided in the overhaul kit.
STEP 288
BP95F198 Remove the small gear.
