INSPECTION OF THE SECONDARY SHAFT NOTE: Clean bearings and gears with clean transmission oil, compressed air, and lint free shop towels.
STEP 236
STEP 234
STEP 237
Check the teeth on the gears for wear and damage. If a tooth is badly damaged, be sure to inspect the gear or spline that is in mesh with the damaged gear.
Check the teeth in the first-second synchronizer assembly for wear and damage. Replace as necessary.
Check the bearings for flat areas, pitting, and other damage. Replace as necessary.
STEP 238 STEP 235 Check the splines on the secondary shaft for wear and damage. Check the passages in the secondary shaft to be sure that the passages are open and free of foreign material.
Bur 7-54022
Check the steel friction ring and tapered bronze ring from the first-second synchronizer for wear or damage. Replace as necessary. Check the springs in the synchronizer assemblies for wear, cracks, heat distortion, and other damage. Replace as necessary.
