ASSEMBLY OF THE INPUT SHAFT STEP 148
STEP 151
BP95F127 Use clean transmission oil to lubricate the sealing rings. Install a sealing ring in each piston. New pistons are provided in the update kit. New seals are provided in the overhaul kit.
BP95F207 Install the spring.
STEP 152
STEP 149
BP95F208 BP95F126 Install the sealing ring on the input shaft in the forward clutch housing. This seal ring is provided in the overhaul kit. Lubricate the input shaft and inside of housing with clean transmission oil.
Install the retainer plate. The side which has a raised area around the bore goes down. The side which has the groove around the bore goes up. The outer edge of the snap ring must fit in this groove after the parts are assembled.
STEP 150
BP95F206 Use clean transmission oil to lubricate the edge and the bore of the piston. Install the piston. Bur 7-54022
