104
ASSEMBLY OF THE TRANSMISSION CONTROL VALVE STEP 431
Use clean transmission oil to lubricate the flow divider piston. Install the flow divider piston in the opposite end of the bore. The closed end of the flow divider piston must be toward the plug in the end of the bore so that the spring will fit inside the open end of the piston..
1 1
1 1
STEP 434 2
BP95F320 Install the four hex head plugs (1) and the Allen head plug (2) using the new copper washers provided in the overhaul kit. Lubricate the bores of the valve body with clean transmission oil.
STEP 432
BP95F314 Install the new spring from the overhaul kit in the bore.
STEP 435
BP95F316 Install a new snap ring from the overhaul kit in the bore as shown. BP95F311
STEP 433 Install the flow divider shaft in the bore.
STEP 436
BP95F313
BP95F312
Bur 7-54022
Issued 10-97
Printed in U.S.A.
