CAB (DELUXE) HEATER CONTROLS (If Equipped) The deluxe heater is located above the operator and is vented into the cab through the head liner. The deluxe heater control switches are located in the right-hand console.
1 1
BD98H005
BP96N054
1. BLOWER FAN SWITCH 2. HEAT TEMPERATURE CONTROL
1. RIGHT CONSOLE
TRIM THIS EDGE
BS99N111
2
1. Blower Fan Switch: The blower fan switch has four positions, (1) OFF, (2) LOW, (3) MEDIUM and (4) HIGH. Turn the switch clockwise to increase the air flow in the cab. Turn the switch counterclockwise to the OFF position to stop the fan. 2. Heat Temperature Control: Turn the temperature control clockwise to increase the heat in the cab. Turn the temperature control counterclockwise to decrease the heat in the cab.
BS99N112
When the heater is not in use the coolant supply valve should be shut off at the engine. Before the heater coolant supply valve c a n b e t u r n e d o ff , t h e o p e r a t o r ’s compartment must be tilted forward. S e e “ Ti l t i n g t h e O p e r a t o r ’ s Compartment Forward” on page 126 for the correct procedure.
1
To shut off the heater coolant supply turn the shutoff valve IN. When the heater is needed, turn the valve OUT to allow hot engine coolant flow through the heater.
BP96N174
1. HEATER COOLANT SHUT OFF VALVE
