INSTRUMENTS/CONTROLS
OPERATORS SEAT Deluxe Seat (If Equipped)
4
3
TRIM THIS EDGE
1
2
BP96N030
1. Forward/ Rearward Adjustment Lever: Move the forward/rearward adjustment lever to the right and slide the seat to the most comfortable position. Release the lever. 2. Seat Suspension Control Knob: While sitting in the operators seat turn this knob to either increase or decrease the seat suspension. As the knob is moved, the indicator arrow will move along the graduated scale showing operator weight settings. 3. Lumbar Adjustment Control Knob: Turn this knob clockwise to increase the lumbar support. To decrease the lumbar support turn the knob counterclockwise. 4. Backrest Tilt Control Knob: Turn the knob clockwise to tilt the operators seat forward. Turn the knob counterclockwise to tilt the operators seat back.
82
