INSTRUMENTS/CONTROLS
LEFT HAND INSTRUMENT PANEL
12 9
10
11
13 BP96N040
TRIM THIS EDGE
9. Seat Belt Reminder: This lamp illuminates and the alarm sounds for 3 seconds when the machine is first started to remind the operator to always wear the seat belt. BS96H055
10. Operators Manual Reminder: This symbol reminds the operator to always check the Operators Manual whenever one of the instrument panel warning lamps illuminate. BS96H054
11. Hourmeter: The hourmeter shows the total hours of engine operation in both hours and tenths of an hour. The hourmeter should be used to measure the time between scheduled maintenance intervals. BS96H096
BS96H097
12. Hydrostatic System Charge Pressure Warning Lamp and Alarm: When the hydrostatic system charge pressure is too low, the warning lamp will illuminate and the alarm will sound. Stop the engine and check for the problem. 13. Systems Normal Lamp: When the machine is in operating condition and all systems are in working condition this lamp will be illuminated.
60
