INSTRUMENTS/CONTROLS
RIGHT HAND INSTRUMENT PANEL (Machines Equipped With Automatic Engine Shutdown System) 8
1 3
2 TRIM THIS EDGE
BD02E001
Display of Stored Information: The AES panel automatically stores information on the amount of time that the skid steer was operated in excess of the operational limits described previously. In addition, the panel stores the number of times the machine was shutdown by the AES system. The information is available for review by following the procedure described below. A. Entering the Review Mode: With the engine stopped and the ignition switch in the OFF position, hold down the Select Button (2). and the Mode Button (3) together. With both buttons depressed, turn the key to the RUN position (the first position when the key switch is turned clockwise). Continue to depress the Select and the Mode Buttons until the Multi-function display (1) displays the following: SHT XX where XX is a number from 1 to 99. B. Total Shutdowns Since the Last Reset: Upon entering the Review Mode, all three of the parameter icon lamps will be illuminated. The information displayed first in the Multi-function display (1) is the total number of machine shutdowns which took place since the last time the panel was reset. This information is displayed in the following format: SHT XX where XX is the number of shutdowns which occurred.
56
