INSTRUMENTS/CONTROLS
RIGHT HAND INSTRUMENT PANEL
8 5
7
TRIM THIS EDGE
6 BP96N041
5. Thermostart (If equipped): If the unit is equipped with a thermostart system, turn the key to the ON position. Depress and hold the rocker switch for 20 to 25 seconds. Turn the key to the START position to start the engine. BS96H057
6. Front Work Lamps: Depress the work light symbol on this switch to turn the work lamps and the red tail lamps on. When the switch is returned to the center neutral position, the work lamps are off. BS96H045
BS96H046
7. Rear Work Lamp: When the rear work lamp symbol is depressed, both the rear and the front lamps are illuminated. When the switch is returned to the center neutral position, the rear and front lamps are off. The red tail lamps do not illuminate when the front and rear work lamps are in operation. 8. Turn Signals (Optional): This symbol illuminates when either the left or the right turn signal is in operation.
BS96H047
48
