MAINTENANCE/ADJUSTMENTS
CAB HEATER Early Production Machines The cab heater is located under the cab floor plate. To gain access to the heater you must remove the floor plate. A
2 1 1
BP98H004
TRIM THIS EDGE
1. CAB HEATER 2. HEATER FILTER
BP98H003
1. HEATER FILTER
The service interval for the heater filter will be determined by the amount of use and the conditions in which the machine is operated. See page 132. To remove the heater filter release the latch and lift up on the filter handle.
Cleaning the Cab Heater Filter To c l e a n t h e f i l t e r c o m p l e t e t h e following procedure. 1. Check the damage.
dirty
element
for
2. Be sure to wear face protection. Remove the loose dirt with compr essed air, 2 b ar (3 0 psi) maximum. Hold the nozzle at least 25 mm (1 inch) from the element.
3. Mix 30 ml (2 tablespoons or 1 oz) of D140 0 de tergent (Ca se part number A40910) with 7.6 litres (2 gallons) of water, 237 ml (1 cup or 8 oz) for 60 litres (13.2 gallons) of water. 4. Soak the element in the soap solution for 15 to 20 minutes and then shake the element up and down rapidly to loosen as much dirt as possible.
BS99K083
182
