CASE HYDRAULIC ATTACHMENT COUPLER (If Equipped)
Installing a Bucket or Attachment IMPORTANT: Before installing a bucket or attachment, make sure the mounting area of the bucket, attachment and Case hydraulic attachment coupler are clean. 2. Tilt the attachment coupler forward and approach the attachment. 3. Engage the attachment mounting brackets.
upper
IMPORTANT: Never leave the machine with the coupler switch in the OFF (rearward) position. BP97N053
NOTE: Consult the instructional decal located on the loader arm crosstube.
1
1. Lift and pull the hydraulic coupler switch rearward to retract the lock pins. Lift and rotate the attachment back.
2 1 BP97D238
1. LOCK PIN GREEN INDICATOR 2. LOCK PIN RED INDICATOR
BP97D002
1. HYDRAULIC COUPLER SWITCH
5. If the lock pin indicator is RED, a ct u a te a n o th e r loa d e r c ir cu it (auxiliary hydra ulics, or loa der down pressure) to increase the engagement pressure.
