OPERATING INSTRUCTIONS
TRANSPORTING THE MACHINE Prior to Loading
WARNING: Overturn Hazard: Park the truck and trailer on a level surface. Make sure the truck, trailer and ramps have enough weight capacity to support the machine. Make sure the truck or trailer deck and ramps are clear of debris or slippery material that can reduce traction. Slowly and carefully move the machine off or onto the truck or trailer ramp. Keep it centered. M473
Observe all work site rules and local ordinance s g overning loading an d transporting the machine. Ensure the hauling unit meets all safety requirements before loading the machine.
See page 37 for rear tie downs on optional drawbar.
1
TRIM THIS EDGE
1. Put a block at the front and rear of the trailer or truck wheels.
1
2. Carefully back the machine slowly onto the trailer. 3. Lower the loader attachment to the trailer deck, stop the engine, and remove the key.
BP96N125
1. FRONT TIE DOWN LOCATIONS
4. Put a block at the front and rear of each machine tire.
6. Measure the clearance height of the machine and trailer or truck. Post the clearance height in the cab of the truck.
5. Fasten the machine to the trailer at the points indicated by the tie down decals.
1
1
BD02E013
1. REAR TIE DOWN LOCATIONS (1EACH RIGHT/LEFT SIDE) (LATE PRODUCTION MACHINES) BP96N020
1. REAR TIE DOWN LOCATIONS
98
