CONTROLS/INSTRUMENTS/ACCESSORIES
WINDSHIELD Template Name: OM_1_col Template Date: 1994_04_29
IMPORTANT: Before opening the windshield, make sure that the windshield wiper is pressing against the windshield and that the forward and rear view mirrors are not folded back against the windshield.
STEP 3
Opening STEP 1
PH08302
Pull the windshield completely back and then push the two handles outwards so as to lock the windshield in position.
TRIM THIS EDGE
IMPORTANT: Make sure that the windshield is securely locked in place.
Closing PE08220
STEP 1
Pull the two handles inward to unlock the windshield and then pull backward.
Alt= to hide template information Alt+ to display template information
STEP 2
PH08302
Pull the two handles inward to unlock the windshield and then push forward. PH07901
Using the handles, move the windshield into horizontal position.
86
